Area51 Project - Old Man to Renegade:



Machine Specs:



1997 Bombardier (Former Grand Touring)

S-2000 Chassis

Rotax 500cc Liquid Cooled, Rotary Valve

Electric Start

Front: ADSA Arm Suspension, Trail Shocks

REV Pilot 5.7 Skis with dual Carbides

Rear: SC10 Skid, Trail Shocks

136"x15"x1.25" Camoplast Rip Saw Track

22/43 Gearing

Snow Stuff Low Smoked Windshield

Mountain Bars, about 5" rise over stock straight bars

Mountain Strap and Bar Pad

Replaced 2 up seat and cargo rack with 1 up seat

Custom LED Taillight

6.5" Machined Aluminum Rear Wheels & Nasty Nuts

Black Skid Plate

Skidoo Gas Caddy

Acerbis Hand Guards

55w 5000k HID Headlight Upgrade






Fall 2008

Spring 2009 Fall 2009 Fall 2010 Fall 2012
Sled Sold Fall 2012

Featured in Sledworthy Magazine


Project Renegade didn't start out as a project at all. This was my first sled and my formal introduction to snowmobiling. I had gotten a taste for it from a few hap-hazard excursions on my Uncles Scandic 377, but owning your own machine makes a world of difference. This 1997 Skidoo Grand Touring 500 was bought used in 2003 so that if I crashed or lost interest in the sport I wouldn't be out too much money. I bought a 2-up touring sled with the intention that I could occasionally carry 2 people and have a rack for carrying ice fishing gear to my favourite ponds. After a couple seasons of snowmobiling, my riding style changed as our crew became more adapt to boondocking, hill climbing, generally fooling around, and riding solo almost all the time.



Before and After, Touring to Renegade

Now the choice was simple, purchase a new sled or invest a few dollars into the one sitting in the garage that was long paid off. For me the choice was clear. As much as I would love to be seated on a brand new REV chassis sled, my practical side prevailed and I knew that other expenses would have to take priority over riding an expensive new sled. I decided to transform my bland Grand Touring "Old Man" sled into what Im sure Bombardier would have called a Renegade like they do their new 136" single seat sleds.  This project was about achieving the best value per dollar spent, building a Renegade sled for a Renegade rider! LoL

If you look at the guts of what separates a touring sled from a play sled, you will find more similarities than youd think. Within the same model year, most of the s-2000 chassis frames are identical. My Grand Touring and a 1997 Summit are both outfitted with a 136" track, similar suspension set ups, identical engines, and aside from clutching and gearing differences the rest is merely cosmetic. Driven with this new information my plan was set and the work began in late fall of 2006 as we eagerly awaited winter's arrival.



The project began by striping off all the bits that defined this sled as a Grand Touring sled. First to go was the tall windshield followed by the low handlebars, rear view mirrors, rear rack, back rest, passenger foot rests, the 2-up seat, and of course the Grand Touring decals on the hood.



I removed the rear slide suspension for a thorough cleaning, painting and replacing of worn parts including these torsion spring mounts that had seen better days! New hyfax were installed and the single limiter strap was replaced with a dual strap set up.



I replaced and/or painted all the outside wheels black, replaced any inside wheels having worn or missing rubber with new wheels and replaced the rest of the bearings throughout the skid as well as the drive shaft bearing opposite the chain case.



The ski carbides had seen better days so a new set was installed to prevent darting.



Next I disassembled and removed the chain case and driveshaft to install my new track.



The track I chose was a 136 x 15 x 1.25" Camoplast Rip Saw. From my research, this was the tallest profile that my chassis could fit without interference, and would provide great hook up in a myriad of conditions (especially compared to my well-used 0.88 profile track!)



While everything was disassembled, I also sourced a used 22 tooth top gear to replace my stock 23 tooth top gear. This lower gearing will provide better launch and low end grunt, especially useful when combined with a more aggressive track.



 The new track is a huge improvement, nearly twice as tall, not worn out, and a lug design that benefits powder and hard pack trails.





With the track replaced and the rear slide and chain case reinstalled, it was on to the handle bars. I sourced a set of used mountain handlebars which had a 5" rise to replace the stock straight bar, the seller also included a matching bar pad and mountain strap. Since the factory hand grips had seen better days, I bartered a pair of new factory REV hand grips/warmers. The bars were installed with little difficulty, careful re-routing of the control cables & wiring was all that was necessary on this machine to accommodate the additional height.



Next on the list was to fabricate a new windshield. With previous success in fabricating one for Project Invader, buying one would be a last resort. I wanted a sleek low windshield to replace the ugly factory tall windshield. I made several templates out of Bristol Board before I had a pattern that I was happy with. A black crazy carpet provided ideal flexible black plastic, using my template I cut the windshield, secured it with the factory push clips and trimmed the edge with self adhesive black automotive door trim. The door trim provided a finished edge and helped strengthen the flexible windshield.





The last major hurdle was to secure a one-up seat, as the two up seat even without the rack did not look right. I quickly realised that finding one used and reasonably priced was like finding a needle in a hay stack. None of the used parts dealers had one and a search of the local online message boards came up empty handed. One day I went to my local dealership to purchase a set of factory running board edge grips and sitting on the clearance rack was a brand new (old stock) one-up seat and it was right in my price range! I purchased the seat and edge grips on the spot and had it installed within the hour. The front mounting points lined up perfectly and two new holes were drilled out back for the rear mounting points. One other modification I made for boondocking and side hilling was the removal of the front sway bar.



Aside from a few minor cosmetic details such as the installation of shed-headz decals, changing the amber reflectors out for white ones and the installation of my custom LED tail light, this project was done and ready for testing.







My first ride impression was outstanding, riding this sled was like finding a new best friend! The new handlebars created a much improved riding position, the running board edge grips now keep my feet firmly planted, both of which allow much more control over the machine when boondocking. The new track combined with the one tooth smaller top gear provided outstanding hook up and power output from stop especially compared to the old set up. To top it off, I was extremely happy with the new sporty appearance of the sled with the one up seat, low windshield and so on. The exposed section of the tunnel out back even allowed me to strap on an extra fuel can for longer rides. At the end of the project I met and exceeded my goals of creating a sled that feels completely new while staying within a reasonable budget.



Fall 2008 Update:

Fall arrived in fine style and  a few repairs and more improvements were made to project Renegade. Over the summer I noticed a small oil leak of clean injection oil coming out of the engine near the water pump. After some research online I learned that this is a weep hole designed to tell of an internal oil seal failure on the rotary valve shaft.



The first step was to remove the water pump, metal backing plate, coolant seal, then the oil seal, installation was reverse of the same steps. I used bombardier parts so I knew they would fit correctly. It would be easier to do this with the exhaust y-pipe removed, but the bolts on mine were very corroded so I worked around it instead of creating another problem to fix!



The stock plastic / metal bridge skis were now 11 years old and beyond their service life. The tip of one was bent and the keel just about non existent.



This year I installed as set of used Pilot 5.7 Skis with dual carbides, the same skis used on new Bombardier sleds.



This was accomplished by removing the stock ski leg bushing and just using a large 5/8" bolt, nut and washers. I cut 2 small pieces of hollow round stock to use as bushings over the bolt to center the ski leg on the ski, and drilled the end of the bolt for a cotter pin to prevent the nut from coming off.



 I also found a new set of machined billet rear idler wheels with "nasty nuts" which just look awesome. The nuts are basically a solid milled aluminum cap over a steel bolt that have a pointed end.



This year I decided to try out a new 19/44 gearing combo which is way way lower than the current 22/44, it should give great low end launch, but I'll have to test it and see if it just digs trenches and how much top end I will be losing.



I also installed a set of blue neon lights under the hood for accent illumination, and fixed the brake light switch.



The new skis are fantastic, they provide better cornering and less darting.



Spring 2009 Update:

During my trip with the Southern Harbour Crew to Black River in February 2009 my machine rolled over 10,000 km and almost immediately developed mechanical trouble! We were way back in the country when the chain case began grinding horribly. Looking at that I also noticed the primary clutch was not working properly. I limited my speed to around 30kph to come out of the country which made for a boring ride, but kept the harsh noises to a minimum. Fortunately everything held together and I managed to ride all the way to Irving in Goobies where some of the crew needed gas. Even though my machine was still moveable it was slow and not reliable, therefore I decided to wait at Irving while the crew went back to Southern Harbour to get my truck and trailer. When I got back to St. John's I finally got to look at the problem.



The first problem was that the outer sheave of the primary clutch was stripped and spinning free of the inner sheave, so the clutch still worked, but was only applying power through the inner sheave. It will probably need to be replaced.



The noises in the chain case were caused by a severely broken bottom gear which damaged the reverse gears and split the case. With the damage to the bottom gear, its a wonder I made it out under my own power, the gear was literally split in two pieces!



Fall 2009 Update:

Young Joe finally wore out the '96 Formula 583 he bought last fall, so I bought what was left of the sled for parts to repair and hopefully improve Project Renegade. The repairs started by removing my damaged inner chain case which was split by forces from the damaged bottom gear. This was replaced with the chain case from the Formula. Unfortunately the Formula did not have reverse, so for the time being I will have to do without as two of my damaged gears were part of the reverse system, but at least my sled will be ride able. During this swap I chose a 22/43 gear set from my parts stock pile which should work well in all conditions. I removed the rear suspension to replace a cracked suspension arm using a replacement part from the Formula.



The 583 engine in the formula was pretty well a direct swap into my chassis using the 583 coolant hoses, clutch and carburetors. Even swapping the 583 carburetor boots into my S-Chassis air box worked out perfect, the electrical was plug and play, and the 583 exhaust system fit right in. I reused all of the 583 throttle cables, removing my stock cables right from the throttle lever and reinstalling the cables from the Formula.

This was a great upgrade as the 583 is much more powerful than the 500 due to increased displacement and the addition of RAVE valves that my 500 did not have. Unfortunately on my 2nd run of the year the oiler failed on the 583 and the engine melted down. In one evening I swapped back  to my trusty 500 and installed a new primary clutch purchased from Reid's Used Parts. It was a busy year, although I'm disappointed that the 583 swap didn't pan out for very long, I'm glad to have this project back on the snow.



This year I also installed a pair of free hand guards from Sooley,



and picked up a REV gas caddy to carry extra fuel on long trips. I bought the gas caddy kit for a REV-XP from Skidoo and bolted the plastic mounts to my tunnel and rear bumper. Its not 100% ideal, but its sturdy, and I can reuse the gas can properly on a REV or REV-XP chassis sled in the future.





Fall 2010 Update:

With my 500cc engine swapped back in, project Renegade is still running strong, although having no reverse really sucks. On the final run last year my rear shock seized/froze solid so I purchased and installed a new Kimpex unit this fall. Upon inspection, I found both front shocks had also started to leak so I replaced them with Kimpex units as well. I've had great success installing HID lighting kits in my trucks so I ordered a kit for the sled. This kit from VVME uses an H4 base with a halogen bulb for Low Beam, and HID for Hi Beam. The HID bulb I chose is  55w unit in 5000k color for a nice white light. My electric starter has been acting up for awhile, so I removed it and repaired a frayed wire on the starter solenoid. A new battery from Wal-Mart now provides easy starts, and constant clean DC power to run my HID headlight.



My old LED taillight broke earlier this year, so I installed a new, larger, clear lens LED taillight purchased at Princess Auto. Its brighter than my old one and looks great installed with a matching chrome mounting bracket.



Fall 2012 Update:

This year I had planned to buy a new sled, but so far it hasn't come to fruition. I had a few things to do whether I decided to keep or sell this sled so I got started. First was the installation of a brand new snow stuff low windshield to replace the broken stock one. On one of our annual winter trips to Sooley's cabin, I rolled the sled doing donuts on a pond cracking the lower portion of the old two piece windshield. I wasn't really a fan of the checker board pattern, but there are pretty much no other options out there for replacement windshields for a 15 year old sled. I installed a new ignition coil as the original one died putting the sled in storage this past spring. I also replaced the outer tie rod ends which removed most of the play in the steering. All in all, the sled has been running great with no complaints all this season.

Cheers, MIKE
